Siser Brick 1000 | Cut-Only Heat Transfer Vinyl

Siser Brick 1000 | Cut-Only Heat Transfer Vinyl Overview

Siser Brick 1000 heat transfer vinyl is an extra-thick 1000 micron PU film for raised garment graphics.

Its substantial construction adds noticeable dimension to suitable logos, lettering and decorative designs.

The material is PVC free and supplied on a non-adhesive polyester liner.

1000 Micron PU Construction

Brick 1000 uses a substantial 1000 micron polyurethane face film.

This creates a much thicker finish than conventional flat heat transfer vinyl.

The raised construction gives garment graphics a stronger three-dimensional appearance.

Designed for Dimensional Garment Graphics

The current product information positions Brick 1000 for smaller logos and designs.

The thick face film adds extra dimension and visual depth after application.

This makes it suitable where a pronounced raised effect is required.

Flexible Thick Film

Despite its thickness, the current product information describes Brick 1000 as flexible.

It is designed to support practical cutting, weeding and garment application.

Always confirm suitability for the intended garment and graphic size.

PVC-Free Heat Transfer Vinyl

The current product information identifies Brick 1000 as PVC free.

This provides another specialist option within Siser’s cut-only garment range.

Matt White and Matt Black

Current live variants are available in Matt White and Matt Black.

Both finishes provide a clean appearance for raised garment graphics.

Choose the colour that best suits the garment and required design contrast.

Compatible Garment Fabrics

The current specification lists 100% polyester and 100% cotton.

It also lists poly/cotton blends and elastane.

Always test unfamiliar garments before full production.

High Washing Resistance

The current product information identifies Brick 1000 as having high washing resistance.

Correct application and garment-care procedures remain important for long-term performance.

155°C Application Temperature

The current application temperature for Brick 1000 is 155°C.

The stated pressing time is 25 seconds.

Medium-high pressure of approximately 3–4 bar is recommended.

Cold Peel Application

The current product specification requires the carrier to be removed cold.

Allow the application to cool before removing the polyester liner.

Cutting and Weeding

The current specification recommends a 60-degree blade.

A cut pressure of approximately 150g is listed.

Always confirm final cutter settings before beginning production.

Juliet and Romeo Cutter Guidance

The current product information includes cutter-specific guidance for Siser Juliet and Romeo machines.

A Deep Cut Blade with green cap is specified for these cutters.

Non-Adhesive Polyester Liner

Brick 1000 is supplied on a non-adhesive polyester liner.

Handle cut and weeded graphics carefully before heat application.

500mm Width and Multiple Roll Lengths

All current live Brick 1000 variants are 500mm wide.

Available roll lengths are 1 metre, 5 metres, 10 metres and 25 metres.

Matt White and Matt Black are available across the current size range.

Professional Raised Garment Decoration

Siser Brick 1000 provides an extra-thick finish for distinctive raised garment graphics.

It combines 1000 micron construction with straightforward cut-only production and heat application.
